Ib tug txheej txheem cej luam ntawm
Lzzbj 9-10 Tus hloov hluav taws xob tam sim no yog Epoxy Retin Casting Rwb thaiv tsev
Cov hom ntsiab lus
Cov xwm txheej ntawm kev siv
1. Qhov ntau dua tsis tshaj 1000 m
2. Lub ambient kub tsis yog siab dua + 40 degree, tsis pub tsawg tshaj 5 degree
3. Ib puag ncig cov huab cua uas nyob ib puag ncig tsis muaj ntau dua 90% (20 degree)
4. Kev teeb tsa muaj cov nyhuv muaj teeb meem loj ntawm transformer rwb thaiv tsev roj, chav, tshuaj lom neeg thiab lwm yam kev qias neeg lossis kev tawm tsam
5. Kev ntsuas chaw tsis muaj kev co thiab cua hlob
Taw qhia txog cov qauv
Pillar ntaus tus ncej hloov tau tag nrho cov qauv, siv cov hlau hlau sib txuas chev, cov thawj thiab theem nrab kauj nrog Retin casting molding molding moulding. Vim muaj lub rwb thaiv tsev ntxiv dag zog, nyob rau hauv cov xwm txheej ntawm kev ua kom noo thiab cov kev ua txhaum cai thib ob yog kev ua haujlwm ib txwm muaj. Rau qhov yooj yim ntawm cov neeg siv rau nruab, muaj peb yam ntawm hom hloov hloov hloov kev sib txuas hom (ntaus a, hom B, C)
Daim ntawv thov
- Fais Fab System
- Nyob rau sab hauv ib puag ncig
- Cov chaw uas ntsuas hluav taws xob tam sim no thiab hluav taws xob hluav taws xob. Piv txwv li, ntau qhov chaw nyob qhov chaw ntsuas hluav taws xob tam sim no thiab hluav taws xob hluav taws xob, xws li cov teeb meem, cov khoom lag luam thiab cov chaw lag luam, thiab lwm yam.
Zuag qhia tag nrho
SS Kos Npe: Ib zaug P1, P2 thiab cov tub ntxhais kawm theem nrab ntawm P1 rau P1 txaus los ntawm S1 ntws los ntawm lub voj sab nraud rau S2, yog rho nyiaj polarity. Thaum muaj lub voj theem twg, lub voj theem nrab yuav tsis qhib, txwv tsis pub muaj hluav taws xob siab yog tsim
Kev tsis muaj
|
Tus qauv |
Rated thawj tam sim no |
Qhov tseeb Theem Ua Ke |
Kev Tso Tawm Rated |
Lub Sij Hawm Luv-thermal tam sim no |
Cov ntsuas kev ruaj khov tam sim no |
|
Lzzbj 9-10 a |
10 |
0.2S/10P10(15) |
10/15 |
2.0 |
5.0 |
|
0.5S/10P10(15) |
10/15 |
2.0 |
5.0 |
||
|
0.2/10P10(15) |
10/15 |
1.0 |
2.5 |
||
|
0.5/10P10(15) |
15/15 |
1.0 |
2.5 |
||
|
15 |
0.2S/10P10(15) |
10/15 |
4.5 |
11.25 |
|
|
0.5S/10P10(15) |
10/15 |
4.5 |
11.25 |
||
|
0.2/10P10(15) |
10/15 |
1.5 |
3.75 |
||
|
0.5/10P10(15) |
15/15 |
1.5 |
3.75 |
||
|
20 |
0.2S/10P10(15) |
10/15 |
6 |
15 |
|
|
0.5S/10P10(15) |
10/15 |
6 |
15 |
||
|
0.2/10P10(15) |
10/15 |
3 |
7.5 |
||
|
0.5/10P10(15) |
15/15 |
3 |
7.5 |
||
|
30 |
0.2S/10P10(15) |
10/15 |
12 |
30 |
|
|
0.5S/10P10(15) |
10/15 |
12 |
30 |
||
|
0.2/10P10(15) |
10/15 |
4.5 |
11.25 |
||
|
0.5/10P10(15) |
15/15 |
4.5 |
11.25 |
||
|
0.2/10P20 |
10/15 |
3.6 |
9 |
||
|
0.5/10P20 |
10/15 |
3.6 |
9 |
||
|
40 |
0.2S/10P10(15) |
10/15 |
16 |
40 |
|
|
0.5S/10P10(15) |
10/15 |
16 |
40 |
||
|
0.2/10P15 |
15/15 |
6 |
15 |
||
|
0.5/10P15 |
15/15 |
6 |
15 |
||
|
0.2/10P20 |
10/15 |
4.8 |
12 |
||
|
0.5/10P20 |
10/15 |
4.8 |
12 |
||
|
50 |
0.2S/10P10(15) |
10/15 |
21 |
52.5 |
|
|
0.5S/10P10(15) |
10/15 |
21 |
52.5 |
||
|
0.2/10P10(15) |
15/15 |
7.5 |
18.75 |
||
|
0.5/10P10(15) |
15/15 |
7.5 |
18.75 |
||
|
0.2/10P20 |
10/15 |
6 |
15 |
||
|
0.5/10P20 |
10/15 |
6 |
15 |
||
|
60 |
0.2S/10P10(15) |
10/15,10/20 |
21 |
52.5 |
|
|
0.5S/10P10(15) |
10/15,10/20 |
21 |
52.5 |
||
|
0.2/10P10(15) |
15/15,10/20 |
9 |
22.5 |
|
Tus qauv |
Rated thawj tam sim no |
Qhov tseeb Theem Ua Ke |
Kev Tso Tawm Rated |
Lub Sij Hawm Luv-thermal tam sim no |
Cov ntsuas kev ruaj khov tam sim no |
|
Lzzbj 9-10 a |
60 |
0.5/10P10(15) |
15/15, 20/20 |
9 |
22.5 |
|
0.2/10P20 |
10/15 |
7.2 |
18 |
||
|
0.5/10P20 |
10/15 |
7.2 |
18 |
||
|
75 |
0.2S/10P10(15) |
10/15 |
31.5 |
78.75 |
|
|
0.5S/10P10(15) |
10/15 |
31.5 |
78.75 |
||
|
0.2/10P10(15) |
15/15 |
10 |
25 |
||
|
0.5/10P10(15) |
15/15 |
10 |
25 |
||
|
0.2/10P20 |
10/15 |
9 |
22.5 |
||
|
0.5/10P20 |
10/15 |
9 |
22.5 |
||
|
100 |
0.2S/10P10(15) |
10/15 |
4 |
112.5 |
|
|
0.5S/10P10(15) |
10/15 |
45 |
112.5 |
||
|
0.2/10P10(15) |
10/15 |
21 |
52.5 |
||
|
0.5/10P10(15) |
15/15 |
21 |
52.5 |
||
|
0.2/10P20 |
10/15 |
12 |
30 |
||
|
0.5/10P20 |
10/15 |
12 |
30 |
||
|
150 |
0.2S/10P10(15) |
10/15 |
45 |
112.5 |
|
|
0.5S/10P10(15) |
10/15 |
45 |
112.5 |
||
|
0.2/10P10(15) |
10/15 |
31.5 |
78,75 |
||
|
0.5/10P10(15) |
15/15 |
31.5 |
78,75 |
||
|
0.2/10P20 |
10/15 |
18 |
45 |
||
|
0.5/10P20 |
10/15 |
18 |
45 |
||
|
200,250 |
0.2S/10P10(15) |
10/15 |
45 |
112.5 |
|
|
0.5S/10P10(15) |
10/15 |
45 |
112.5 |
||
|
0.2/10P10(15) |
10/15 |
45 |
112.5 |
||
|
0.5/10P10(15) |
15/15 |
45 |
112.5 |
||
|
0.2/10P20 |
10/15 |
24 |
60 |
||
|
0.5/10P20 |
10/15 |
24 |
60 |
||
|
300 |
0.2S/10P10(15) |
10/15 |
63 |
157.5 |
|
|
0.5S/10P10(15) |
10/15 |
63 |
157.5 |
||
|
0.2/10P10(15) |
10/15 |
45 |
112.5 |
||
|
0.5/10P10(15) |
15/15 |
45 |
112.5 |
||
|
0.2/10P20 |
10/15 |
36 |
90 |
||
|
0.5/10P20 |
10/15 |
36 |
90 |
||
|
400 |
0.2S/10P10(15) |
10/15 |
63 |
157.5 |
|
|
0.5S/10P10(15) |
10/15 |
63 |
157.5 |
||
|
0.2/10P10(15) |
10/15 |
63 |
157.5 |
||
|
0.5/10P10(15) |
15/20 |
63 |
157.5 |
||
|
0.2/10P20 |
10/15 |
48 |
120 |
||
|
0.5/10P20 |
10/15 |
48 |
120 |
||
|
500 |
0.2S/10P10(15) |
15/20 |
63 |
157.5 |
|
|
0.5S/10P10(15) |
15/20 |
63 |
157.5 |
||
|
0.2/10P10(15) |
15/20 |
63 |
157.5 |
|
Tus qauv |
Rated thawj tam sim no |
Qhov tseeb Theem Ua Ke |
Kev Tso Tawm Rated |
Lub Sij Hawm Luv-thermal tam sim no |
Cov ntsuas kev ruaj khov tam sim no |
|
Lzzbj 9-10 a |
500 |
0.5/10P10(15) |
20/20 |
63 |
157.5 |
|
0.2/10P20 |
15/15 |
63 |
157.5 |
||
|
0.5/10P20 |
15/15 |
63 |
157.5 |
||
|
600 |
0.2S/10P10(15) |
15/20 |
63 |
130 |
|
|
0.5S/10P10(15) |
15/20 |
63 |
130 |
||
|
0.2/10P10(15) |
15/20 |
63 |
130 |
||
|
0.5/10P10(15) |
20/20 |
63 |
130 |
||
|
0.2/10P20 |
15/15 |
63 |
130 |
||
|
0.5/10P20 |
15/15 |
63 |
130 |
||
|
1200 |
0.2S/10P10(15) |
15/20 |
80 |
160 |
|
|
0.5S/10P10(15) |
15/20 |
80 |
160 |
||
|
0.2/10P10(15) |
15/20 |
80 |
160 |
||
|
0.5/10P10(15) |
20/20 |
80 |
160 |
||
|
0.2/10P20 |
15/20 |
80 |
160 |
||
|
0.5/10P20 |
15/20 |
80 |
160 |
||
|
2500 |
0.2S/10P10(15) |
15/30 |
80 |
160 |
|
|
0.5S/10P10(15) |
15/30 |
100 |
200 |
||
|
0.2/10P10(15) |
15/20 |
100 |
200 |
||
|
0.5/10P10(15) |
15/20 |
100 |
200 |
||
|
0.2/10P20 |
20/20 |
100 |
200 |
||
|
0.5/10P20 |
15/20 |
100 |
200 |
||
|
3000 |
0.2S/10P10(15) |
15/20 |
100 |
200 |
|
|
0.5S/10P10(15) |
15/30 |
100 |
200 |
||
|
0.2/10P10(15) |
15/20 |
100 |
200 |
||
|
0.5/10P10(15) |
20/20 |
100 |
200 |
||
|
0.2/10P20 |
15/20 |
100 |
200 |
||
|
0.5/10P20 |
15/20 |
100 |
200 |
Nco tseg:Qhov saum toj no technical tsis yog rau qhov ntsuas tus kheej thib 5a. Yog tias koj xav tau 1a lossis lwm cov ntaub ntawv, thov hu rau peb thaum tso ib qho kev txiav txim.
